Application
The TBE1 terminal boxes are designed for taps, splices or connecting of conductors for control and instrument.
These boxes are suitable for explosive atmospheres zone 1, 2 and zone 21, 22.
Specification
- Housing material : Marine grade copper-free aluminium alloy with polyester powder coated, RAL 7032 (Grey) (optional offshore paintingacrylic polyurethane coating)
- Sealing (O-ring) : Silicone -40°C to +175°C
- Bolts : Stainless steel, SUS 304 (optional SUS 316)
Electrical Rating
- Rated voltage : up to 630V.
- Rated current : up to 41A.
(depending on type of terminal used)
Option
please specify
- Terminal sizes and number of poles
